SC60-SD DTH hammer

Material: quality alloy steel
SC60-SD hammer shank: SD6
Air pressure: 10-25 bar / 145-363 PSI
Regular drill bit diameter: 165mm, 171mm, 178mm,190mm
Color: optional
Package: plywood case per each hammer
MOQ: one pc
Customized: Yes
  • SC60-SD

  • SOLLROC

Availability:
Quantity:

Product Description

Overview

SOLLROC SC60-SD DTH hammer is proven by testing and using in many job sites for varies rock conditions. It is used for varies applications, including mining, exploration, water well, geothermal,construction drilling and civil engineering.

Features

1、Valveless air distribution ensures smooth working.

2、Piston design and harden wear part ensure strong wear-resistance

3、Minimize the energy loss, high penetration, lower air and oil consumption.

4、Fewer internal parts minimize the maintain and replace the part requirements.

Total parameter list

Model

SC60-SD

Bit shank

SD6

Top sub thread

API 3 1/2" REG

Length (less bit)

1261mm (49.65 in)

External diameter

142mm (5.59 in)

Weight (less bit)

100kg (220lbs)

Impact rate at 17 bar

25HZ

Hole range

152mm-190mm (6 in -7.48 in)

Working pressure

10-25 bar

Speed recommended

25-50 rpm

Pull force recommended

11 KN


Drill bits

Dia.

Button configuration Qty*dia.

Bit design

Weight(kg)

Part number

Metric

Inch

Guage button

Front button

165mm

6 1/2"

8*Ф18mm

8*Ф16mm

Flat face

21.6

SC60-M-165FF

165mm

6 1/2"

8*Ф18mm

4*Ф16mm,4*Ф16mm

Convex face

21.4

SC60-M-165CV

165mm

6 1/2"

8*Ф18mm

6*Ф16mm,4*Ф15mm

Concave face

21.1

SC60-M-165CC

171mm

6 3/4"

8*Ф18mm

6*Ф16mm,4*Ф16mm

Concave face

21.8

SC60-M-171CC

178mm

7"

8*Ф18mm

6*Ф16mm,4*Ф16mm

Concave face

22.4

SC60-M-178CC

190mm

7 1/2"

10*Ф18mm

8*Ф16mm,5*Ф16mm

Concave face

23.9

SC60-M-190CC
